Tổng quan
Thích hợp cho mẫu vật dài (Tối đa 3500 mm)
Phạm vi ứng dụng: ô tô, hàng không vũ trụ và công nghiệp sản xuất
Thích hợp cho mẫu vật lớn, phụ tùng ô tô, mẫu vật dài và trục khuỷu
| 10” HMI touch panel
Intelligent variable feeding rate will adjust automatically, which depends on material and hardness of specimen
|
Dual spindles can cut simultaneously
Cutting crankshaft with multiple serial cutting function and hydraulic vise (Optional)
Dual spindles cutting can greatly lower labor force and reduce time of replacing vises |
Thông số kĩ thuật
| Model | CK-2S-100 | ||
| Travel Distance (mm) | Feeding Travel Distance | 450 | |
| Right Spindle Travel Distance | 220 | ||
| Left Spindle Travel Distance | 220 | ||
| Motor Power | 10HP x 2 (7500W x 2) | ||
| Cutting Ability (mm) | Max. Ø100 | ||
| Cut-Off Blade (mm) | Max. Ø406 x Ø31.75 (Ø32 ) | ||
| Feeding Rate (mm/s) | 0.001~50 | ||
| Rotational Speed (rpm) | 2500 rpm (60Hz)±50% (1250~3750 rpm) | ||
| 2100 rpm (50Hz)±50% (1050~3150 rpm) | |||
| Feeding Method | Auto: | 6 modes, including multiple serial
cutting modes and pulse cutting function |
|
| Manual: | Electric hand wheel | ||
| Size of T-Slot Table (mm) | 500 x 438 | ||
| Machine Dimension WxDxH (mm) | 3180x1730x2000 | ||
| Machine Weight (kg) | 3000 | ||
| Power Supply (V) | AC 220V/380V/415V/440V 3Ø | ||
| (special voltage can be customized) | |||
