| Specification | 260F | 360F | |||
| Motor power | 3HP (2300W) | 5HP (3800W) | 7.5HP (5600W) | 10HP (7500W) | |
| Sample Dim Max.(mm) | MaxØ70mm
20t×100L |
MaxØ90mm
25t×100L |
MaxØ90mm
30t×150L |
MaxØ120mm
30t×15 L |
|
| Cut off blade(mm) | MaxØ305× Ø31.75 | MaxØ355× Ø32 | MaxØ406× Ø32 | MaxØ406×
Ø32 |
|
| Feeding rate | 0~150 mm/min (Min:25) | 0~75 mm/min (Min:25) | |||
| Feeding Method | Auto | Button control. Home point return after cutting | |||
| Manual | Hand wheel or button control | ||||
| Rotational speed | 2500 RPM (60Hz) / 2100 RPM (50Hz) | ||||
| Cutting depth(X) | 260mm | 260mm | 360mm | 360mm | |
| Vertical movement(Z) | 80mm | 120mm | |||
| Vise | T-slot vise table with left/right separately vises | ||||
| Vise capacity (max.) | Right vise table 95x390mm
Left vise table 200×390 Open 200MMx85mm |
||||
| Horizontal movement | With the right/left vises a movement 45mm in ← → direction | ||||
| Cooling | 1/4HP(190W) Three phases | ||||
| Water tank capacity | 25gal (100L) | 30gal (120L) | |||
| Machine size
(WxDxH) |
1050x1250x1620mm | ||||
| Weight | 830kg | 900kg | |||
| Power supply | AC 220V/380V/415V/440V Three phases
(Special voltage can be ordered) |
||||
| Optional vise | Acceptable special vise ordered | ||||
| Standard accessories | Wrenchx2pcs, cut off bladex2pcs | ||||
| Coolant 5L | Coolant 6L | ||||
