Máy Đúc Mẫu Nóng Toptech L- L/E3

Giá: Liên hệ

184 Bình Than, P. Võ Cường, Tp. Bắc Ninh

Thứ 2 - 6: 8h00 - 17h30
Thứ 7: 8h00 - 12h00

Tổng quan

Model No.	L					L-E3
Sample dia.	Ø25mm	Ø32mm	Ø40mm		Ø50mm	Ø25mm	Ø32mm			Ø40mm	Ø50mm
Driven method	High efficiency motor driven & Hydraulic control
Sample qty.	1pc/per time- Note1					1~3 pc/per time
Temperature	0~250°C-Note 3
Noise level (idle running)	59~63dB		59~66dB			61~64dB				62~68dB
Heating power	1200W		1600W			2400W				3200W
Motor power	1600W		2000W			2800W				3600W
Hydraulic system	Ø50x140mm					Ø50x210mm
Pressure adding	0~200kg/cm² (1 kg/cm2/unit)-note 4
Heating time	Max.60 minutes
Cooling time	Max.30 minutes
Memory modes	10 sets (Can set heating temperature、heating time and cooling time)
Machine size (WxDxH)	39x55x55cm					39x55x69cm
Weight	64Kg		65Kg			67Kg				70Kg
Water inlet and outlet pipes	10mm pipes (inner dia.Ø10mm－Outer dia.Ø15mm)
Cooling system	Electronic water valve connect outside cooling recycle system
Power supply	AC220V-1 Ø (Special voltage can be ordered)
Standard accessories	Tweezer：1pc			Funnel：1pc					Filter：1set
	Spoon：1pc			Mounting resin：1kg(2.2lb)				Water pump：1set
	Pipe clip：4pcs			Copper fitting：1pc				Spacer(E3)：2pcs
	Acrylic powder:2kgs(4.4lb)
Option	Cylinder kit

Thương hiệu	Toptech
