| Features | |
| Superior industrial plastic body
Exquisite Appearance Streamline appearance design and glossy film surface finishing makes the mechanical appearance artistic and exquisite.
Intuitive design and metal button operating panel Equipped with durable high-quality metal buttons makes the design Intuitive. |
|
|
Rotational speed of the head is adjustable The grinding head is equipped with brushless motor with rotation speed from 10~170rpm |
Dispenser (Optional) External dispenser can precisely control polishing process and replicate the same procedure.
|
|
Automatic drying function The graphic visualization drying function can make the cleaning process more fast in order to avoid the cross contamination during the operating process.
|
Low speed grinding and polishing function Grinding speed can be adjusted to a minimum of 10 rpm. With external dispenser, it can meet the need of long-time polishing without deformation.
|
|
Modular design The combined control box can be fixed behind the machine or be placed next to the machine with quick-change design, which is easy to clean and can maximize the space.
Individual pressure (A type and B type) The press force is 1.4~5kg which can be controlled based on the material of the specimen.
Central pressure (C type) The press force is 3~5kg which can be controlled based on the material of the specimen.
|
Various choices of platen Platen size of 8” and 10”are suitable for any consumables application.
|
| Retractable water hose
Clean the machine conveniently. |
|
| Various anti-splash application
Various anti-splash covers can be applied based on the method of polishing process.
|
 |
| Model | P20G-2-A3 | P20G-2-B3 | P20G-2-C3 | P25G-2-A3 | P25G-2-B3 | P25G-2-C3 |
| P20G-2-A5 | P20G-2-B5 | P20G-2-C4 | P25G-2-A5 | P25G-2-B5 | P25G-2-C4 | |
| Platen Size (mm) | Ø203.2 (8”) | Ø254 (10”) | ||||
| Platen Quantity | 2 | |||||
| Grinding Method | Individual force | Individual force | Central force | Individual force | Individual force | Central force |
| Calibration | No | Yes | Yes | No | Yes | Yes |
| Grinding Quantity (pcs) | 3 or 5 | 3 or 4 | 3 or 5 | 3 or 4 | ||
| Sample Size (mm) | Ø25/Ø32/Ø40
(Special sample size can be customized) |
Ø15~Ø32
Ø20~Ø40 |
Ø25/Ø32/Ø40
(Special sample size can be customized) |
Ø15~Ø32
Ø20~Ø40 |
||
| Force (kg) | 1.4~5 | 3~5 | 1.4~5 | 3~5 | ||
| Platen Motor Power (W) | 400 | |||||
| Platen Rotational Speed (rpm) | 1~600 (Effective Rotational Speed 10~600) | |||||
| Head Motor Power (W) | 50 | |||||
| Head Rotational Speed (rpm) | 10~170 | |||||
| Timer (min: s) | 99:59 | |||||
| Machine Dimension
WxDxH (mm) |
880x650x680 | |||||
| Machine Weight (kg)
AC110V 1Ø |
96 | 98 | ||||
| Machine Weight (kg)
AC220V 1Ø |
86 | 88 | ||||
| Standard Accessories | Grinding Platen 1pc, O-Ring 1pc, Polishing Platen 1pc, Anti-Splash Cover 4pcs, Silicon Carbide Paper 8 pcs, Polishing Cloth 2pcs, Aluminum Oxide Powder 100g, Filter 1 set, 500g Dispenser 1 pc, Leveler (C type only) | |||||
| Option | P20F0027 Dispenser Set for One Bottle, P20F0028 Dispenser Set for Four Bottles, PA0108-1 8” Anti-Splash Cover (Manual), PA0108 10” Anti-Splash Cover (Manual), PA0108-3 8” Anti-Splash Cover (Auto), PA0108-4 10” Anti-Splash Cover (Auto), PA0108-2 Anti-Splash Cover (Full-Cover) | |||||
